Description
The MA-101ACT system is designed so that each teacher can carry their own personal wireless microphone from classroom to classroom.
The MIPRO MA-101ACT remote-controlled wireless PA system allows a single MT-101ACT wireless mic to be operated in multiple rooms without cross-modulation. Ideal for classrooms, training rooms and meeting rooms. As well as the benefits to the audience of clearly amplified speech, this system will help to alleviate stress on the lecturer’s voice and has the hygienic bonus that each presenter can have their own microphone.
A traditional portable PA system requires a PA amplifier plus a matching frequency wireless microphone in each room. For example, in 4 rooms there would be a total of 4 PA amplifiers and 4 matching wireless microphones.
However with the innovative design of MA-101ACT system the user simply uses the same wireless microphone in any of the four rooms that are installed and frequency programmed. With a simple touch of a button the microphone is automatically synced to the PA amplifier’s frequency in each room and PA is ready to use.
Up to 97 different rooms using the same wireless microphone is possible.
|
Portable PA |
|
|
Max. Power Output |
45 Watts |
| Amplifier | Class AB |
| Sensitivity | Typical: 95 dB | Maximum: 107 dB |
| T.H.D. | < 1% |
| Frequency Response | 60 Hz ~ 15 kHz |
| Loudspeaker | 5 ” full-range, high efficiency |
| Audio Inputs | Wired: 6.3 mm (1/4 “) optional MM-107 microphone Line-In: 3.5 mm (1/8 “) |
| Audio Output | 3.5 mm (1/8 “) |
| Installation | Microphone stand, table mounted, shoulder belt. |
| Power Supply | AC: External 100 ~ 240V AC switching power supply DC & Battery: 14.8 V / 2.6 AH rechargeable lithium battery (MB-25) |
| Charge Time | Up to 4 hours (automatic charging management) |
| Standby Time | Up to 10 hours |
| Battery Indicator | Single LED indicator |
| Color | Grayish Black |
| Dimensions (W × H × D) | 160 × 178 × 285 mm / 6.3 x 7 x 11.2 “ |
| Weight (battery included) | Approx. 2.2 kg / 4.8 lbs |
|
Wireless System |
|
|
Receiver Channel |
Single |
|
Frequency Range |
UHF 480 ~ 934 MHz (country dependent) |
| Bandwidth | 24 MHz |
| Preset Channel | 16 |
| Channel Set-up | Scan & ACT sync |
| Antenna | Built-in |
|
Patents & Approvals |
Patented. Telecom and safety regulations approved. |
|
Notes |
Refer to actual product in the event of product discrepancy. |
Ideal applications include:
- Multiple classrooms
- Multiple meeting rooms
- Multiple training rooms
- Tours for factories, companies, museums, zoos
