Description
The UBEX range of AVoIP products from Lightware are an ideal solution when you want no compromise, uncompressed, high resolution AV over a 10G network. With ultra low latency and seamless switching it is an ideal solution for broadcasting or live events, in fact there are even dedicated rental and staging market versions available specifically developed for these markets. They have a range of configurations modes including being used as splitters, extenders, switchers or in a matrix with multiple sources and displays.
UBEX is often used in staging, rental applications and also marine installations, safety critical systems and 3D visualisation systems.
Using dual 10G fibre connections gives the system up to 20Gb bandwidth.
Features
■ 4K UHD @ 60Hz 4:4:4 Scaler
■ Multi-streaming technology (multiple video transmission on a single optical link)
■ Video Over IP OR Point-to-Point operation modes: UBEX can also work as a conventional extender, no Ethernet switch is required for simple extension
■ Versatile operation modes: dual channel 4K transmitter or receiver or transceiver mode: sending and receiving signals simultaneously
■ Operation modes can be changed by rebooting and selecting the desired mode
■ Field replaceable SFP+ modules: up to Singlemode (SM) 80 km or Multimode (MM) 400 Meters
■ Advanced EDID Management
■ 10 Gbps on one (or two) fibres OR 20 Gbps on two (or four) fibres
■ Virtual Matrix mode with UBEX units connected to a central Ethernet switch serving as cross point, supervised and controlled by a UBEX MMU-X200 Matrix Management Unit
■ Front panel jog dial push button and colour display
■ Front panel feedback LEDs
■ Internal power supply and front-to-back cooling air trail
■ Source Locked – Low Latency Mode: receivers can be set to source-locked mode when the video transmission latency is very low
